Tongue Jacks

After Market Distributor Product

Description

Tongue jacks are used for lifting and lowering the tongue of a trailer when connecting it to or disconnecting it from the tow vehicle. Tongue jacks are also used for leveling the trailer when camping.

    • Corrosion Protection – Jack tubes are coated with a rust inhibitive process called E-coat. The coating exceeds the A.S.T.M. standard 2000 hour salt spray test. The coating can also serve as primer for custom paint finishes.
    • Precision Metal Gears – All BAL jacks incorporate precision molded, heat treated, copper alloyed metal gears and nuts.
    • High Performance Bearings.
    • Protective Lubricant – The internal screw is coated from top to bottom with a specially formulated lubricant that provides increased protection against wear and corrosion.
    • High Strength Tubing.
    • Top-wind models have a high strength ergonomic handle.
    • Side-wind models have an accessible gear housing making it easier to lubricate and repair.







MODEL CAPACITY A

(Retracted to Extended)

B C D TUBE

INNER

TUBE

OUTER

29015 1000 7-1/2” to 21-1/2″ 14-1/2” 6” 4-1/2” 1-5/8” 1-7/8”
29025 1000 8″ to 22″ 13-1/2” 6” 6-1/2” 2” 2-1/4”
29020 1000 7-1/2” to 21-1/2″ 12-1/2” 6-1/2” 4-3/4” 1-5/8” 1-7/8”
29024 1000 5-1/2” to 19-1/2″ 14-1/2” 6-1/2” 4-3/4” 1-5/8” 1-7/8”
29022 1000 5-1/2” to 19-1/2″ 14-1/2” 6-1/2” 4-3/4” 1-5/8” 1-7/8”
29030 2000 8” to 22″ 12” 6-1/2” 4-3/4” 2” 2-1/4”
29033 5000 8” to 22″ 12” 7-1/2” 4-3/4” 2” 2-1/4”

WARNING: Cancer & Reproductive Harm. www.P65Warnings.ca.gov

MODEL CAPACITY A

(Retracted to Extended)

B C D E INNER TUBE OUTER TUBE
29001 800 12-1/2″ to 25″ 12-1/2″ 6” 5-1/2” 6-1/2″ 1-3/4” 2”
29005 800 12-1/2″ to 25″ 11″ 6” 6-1/2” 6-1/2″” 1-3/4” 2”
